Merge pull request #9 from lawrencehj/master

增加了PTZ控制指令码的实现

src/main/java/com/genersoft/iot/vmp/gb28181/SipLayer.java

@@ -59,10 +59,10 @@ public class SipLayer implements SipListener, Runnable {

 	@PostConstruct
 	private void initSipServer() {
-		Thread thread=new Thread(this);
-        thread.setDaemon(true);
-        thread.setName("sip server thread start");
-        thread.start();
+		Thread thread = new Thread(this);
+		thread.setDaemon(true);
+		thread.setName("sip server thread start");
+		thread.start();
 	}

 	@Override
@@ -84,7 +84,7 @@ public class SipLayer implements SipListener, Runnable {
 			 * 0; public static final int TRACE_MESSAGES = 16; public static final int
 			 * TRACE_EXCEPTION = 17; public static final int TRACE_DEBUG = 32;
 			 */
-			properties.setProperty("gov.nist.javax.sip.TRACE_LEVEL", "0");
+			properties.setProperty("gov.nist.javax.sip.TRACE_LEVEL", "32");
 			properties.setProperty("gov.nist.javax.sip.SERVER_LOG", "sip_server_log");
 			properties.setProperty("gov.nist.javax.sip.DEBUG_LOG", "sip_debug_log");
 			sipStack = (SipStackImpl) sipFactory.createSipStack(properties);
@@ -99,13 +99,15 @@ public class SipLayer implements SipListener, Runnable {
 	}

 	private void startTcpListener() throws Exception {
-		ListeningPoint tcpListeningPoint = sipStack.createListeningPoint(sipConfig.getSipIp(), sipConfig.getSipPort(), "TCP");
+		ListeningPoint tcpListeningPoint = sipStack.createListeningPoint(sipConfig.getSipIp(), sipConfig.getSipPort(),
+				"TCP");
 		tcpSipProvider = sipStack.createSipProvider(tcpListeningPoint);
 		tcpSipProvider.addSipListener(this);
 	}

 	private void startUdpListener() throws Exception {
-		ListeningPoint udpListeningPoint = sipStack.createListeningPoint(sipConfig.getSipIp(), sipConfig.getSipPort(), "UDP");
+		ListeningPoint udpListeningPoint = sipStack.createListeningPoint(sipConfig.getSipIp(), sipConfig.getSipPort(),
+				"UDP");
 		udpSipProvider = sipStack.createSipProvider(udpListeningPoint);
 		udpSipProvider.addSipListener(this);
 	}
@@ -127,13 +129,15 @@ public class SipLayer implements SipListener, Runnable {
 		if ((status >= 200) && (status < 300)) { // Success!
 			ISIPResponseProcessor processor = processorFactory.createResponseProcessor(evt);
 			processor.process(evt, this, sipConfig);
+		} else if (status == Response.TRYING) {
+			// trying不会回复
 		} else {
 			logger.warn("接收到失败的response响应！status：" + status + ",message:" + response.getContent().toString());
 		}
 		// trying不会回复
-		if (status == Response.TRYING) {
+		// if (status == Response.TRYING) {

-		}
+		// }
 	}

 	/**

src/main/java/com/genersoft/iot/vmp/gb28181/transmit/cmd/impl/SIPCommander.java

@@ -94,6 +94,49 @@ public class SIPCommander implements ISIPCommander {
 		return ptzCmd(device, channelId, 0, 0, inOut, 0, zoomSpeed);
 	}

+   /**
+	* 云台指令码计算
+	*
+    * @param leftRight  镜头左移右移 0:停止 1:左移 2:右移
+    * @param upDown     镜头上移下移 0:停止 1:上移 2:下移
+    * @param inOut      镜头放大缩小 0:停止 1:缩小 2:放大
+    * @param moveSpeed  镜头移动速度 默认 0XFF (0-255)
+    * @param zoomSpeed  镜头缩放速度 默认 0X1 (0-255)
+    */
+    public static String cmdString(int leftRight, int upDown, int inOut, int moveSpeed, int zoomSpeed) {
+		int cmdCode = 0;
+		if (leftRight == 2) {
+			cmdCode|=0x01;		// 右移
+		} else if(leftRight == 1) {
+			cmdCode|=0x02;		// 左移
+		}
+		if (upDown == 2) {
+			cmdCode|=0x04;		// 下移
+		} else if(upDown == 1) {
+			cmdCode|=0x08;		// 上移
+		}
+		if (inOut == 2) {
+			cmdCode |= 0x10;	// 放大
+		} else if(inOut == 1) {
+			cmdCode |= 0x20;	// 缩小
+		}
+		StringBuilder builder = new StringBuilder("A50F01");
+		String strTmp;
+		strTmp = String.format("%02X", cmdCode);
+		builder.append(strTmp, 0, 2);
+		strTmp = String.format("%02X", moveSpeed);
+		builder.append(strTmp, 0, 2);
+		builder.append(strTmp, 0, 2);
+		strTmp = String.format("%X", zoomSpeed);
+		builder.append(strTmp, 0, 1).append("0");
+		//计算校验码
+		int checkCode = (0XA5 + 0X0F + 0X01 + cmdCode + moveSpeed + moveSpeed + (zoomSpeed /*<< 4*/ & 0XF0)) % 0X100;
+		strTmp = String.format("%02X", checkCode);
+		builder.append(strTmp, 0, 2);
+		return builder.toString();
+}
+
+
 	/**
 	 * 云台控制，支持方向与缩放控制
 	 *
@@ -109,13 +152,14 @@ public class SIPCommander implements ISIPCommander {
 	public boolean ptzCmd(Device device, String channelId, int leftRight, int upDown, int inOut, int moveSpeed,
 			int zoomSpeed) {
 		try {
+			String cmdStr= cmdString(leftRight, upDown, inOut, moveSpeed, zoomSpeed);
 			StringBuffer ptzXml = new StringBuffer(200);
 			ptzXml.append("<?xml version=\"1.0\" ?>");
 			ptzXml.append("<Control>");
 			ptzXml.append("<CmdType>DeviceControl</CmdType>");
 			ptzXml.append("<SN>" + (int)((Math.random()*9+1)*100000) + "</SN>");
 			ptzXml.append("<DeviceID>" + channelId + "</DeviceID>");
-			ptzXml.append("<PTZCmd>" + "</PTZCmd>");
+			ptzXml.append("<PTZCmd>" + cmdStr + "</PTZCmd>");
 			ptzXml.append("<Info>");
 			ptzXml.append("</Info>");
 			ptzXml.append("</Control>");
@@ -123,7 +167,6 @@ public class SIPCommander implements ISIPCommander {
 			Request request = headerProvider.createMessageRequest(device, ptzXml.toString(), "ViaPtzBranch", "FromPtzTag", "ToPtzTag");

 			transmitRequest(device, request);
-
 			return true;
 		} catch (SipException | ParseException | InvalidArgumentException e) {
 			e.printStackTrace();

src/main/resources/application.yml

@@ -26,7 +26,8 @@ spring:
 server:
     port: 8080
 sip:
-    ip: 10.200.64.63
+#   ip: 10.200.64.63
+    ip: 192.168.0.102
     port: 5060
     # 根据国标6.1.2中规定，domain宜采用ID统一编码的前十位编码。国标附录D中定义前8位为中心编码（由省级、市级、区级、基层编号组成，参照GB/T 2260-2007）
     # 后两位为行业编码，定义参照附录D.3
@@ -34,7 +35,8 @@ sip:
     domain: 3701020049
     id: 37010200492000000001
     # 默认设备认证密码，后续扩展使用设备单独密码
-    password: admin
+    password: admin123
 media:
-    ip: 10.200.64.88
+#   ip: 10.200.64.88
+    ip: 192.168.0.102
     port: 10000
